SEA EX 2/22
Zone 2/22 Ex nR LED luminaire for marine and offshore operations
High variability and modularity
Glass or polycarbonate body, various lengths, output options, optics, color temperatures
high durability
Protection rating IP68, resistant to extreme weather conditions as well as chemical vapors
high efficacy
Highly efficient luminaires with up to 177 lm/W
-
Designed for use on seagoing vessels, offshore platforms, wind power plants but also
in agriculture farms, chemical plants and similar demanding environments -
The SEA luminaire is available with various lengths and output versions from 19.6 W to 39.2 W
-
The luminaire can be equipped with an emergency battery
-
6-year guarantee
-
The IP68 enclosure is resistant to seawater and most chemical vapors
-
Borosilicate tempered glass or UV stable PC
-
Optional correlated colour temperature standard 3000–6500K
-
Operating temperatures –40 °C ~ +50 °C
Low glare with high efficiency
Although the high efficiency of the product, doublepower!! ONE ensures perfect lighting comfort and low glare. At all mounting heights and at any lighting level, its glare values remain well below the permissible limits. We manage to achieve this unique combination of high efficiency and low glare due to the use of a new type of optics.
- Lifespan of the luminaire 80.000 hours (L80B10)
- A quick and simple installation using A4-steel anti corrosive mounting rings
- Available color temperatures
- An entire range of optics 40°, 60°, 90°, and 110°, asymmetric characteristic available
